TURRET
10
Up to
BAR CAPACITY
1.65
Up to
"
The Diamont Swiss Turn Hybrid comes with the Mitsubishi M80 Control loaded with options, including the VCC (Chip Breaking Feature) and a powerful 12 station Eurotech turret with BMT55 holders (huge array of tooling options and flexibility).
3 Tools in the Cut with Eurotech EGS Tooling
Drastic Cycle Time Reduction
Power Meets Flexibility
With a Mitsubishi 830 control system, the Diamont offers unparalleled ease of use and flexibility. It not only simplifies conversions between guide bushing and non-guide bushing setups but also supports an impressive array of up to 61 tools. The substantial horsepower—10 HP on the main spindle *and * sub-spindle—enables faster material removal and the use of larger drills. Additionally, compatibility with any major brand of guide bushing and collet ensures a straightforward setup process.
Hybrid Swiss
Superimposition with Eurotech EGS Tooling.
Hydraulic Brake/Cylinder Clamping
More Control. More Precision.
The Diamont's included hydraulic disc brake assists in removing more material during milling and also reducing the stress on the C-axis throughout the machining process. Additionally, the increased cylinder clamp force is a significant benefit for ID work and also reduces bar pushback.
Powerful 12 Station Eurotech Turret
Strength. Secured.
The Diamont's integrated power 12 station turret is designed to utilize Eurotech's EGS. Additionally the Diamont uses the BMT55 holders and has directly driven live tooling on all positions with no belts. Up to 3 tools can work simultaneously. The rotary tools are driven by a motor with 16.2 lb.ft torque, 6.1 HP power and speed range of 6000 rpm.
3-year control warranty, parts and labor
Protected Performance
Our comprehensive 3-year warranty on the control system, covering both parts and labor, underscores our commitment to reliability and satisfaction. This robust warranty ensures that your investment is protected, offering peace of mind and significantly reducing the potential for unforeseen costs associated with parts replacement or labor charges.
Free Lifetime Support and Programming Training
Confidence Standard
For over two decades, Eurotech has championed unparalleled customer support through our commitment to FREE lifetime training and phone support, ensuring our clients not only get the machines they’re looking for, but also the knowledge and assistance they need for sustained profitability. Eurotech College has become a cornerstone for our customers nationwide, offering comprehensive training at no extra cost. Complementing this, our FREE lifetime phone support provides immediate access to an extensive network of experts, from software engineers to hardware specialists, ready to tackle any challenge at a moment's notice. This dual approach guarantees that whether you're looking optimize machine performance, navigate technical issues, or master your operations, a skilled professional is always within reach to ensure your operations proceed without interruption, enhancing your productivity and efficiency.
Robust Mitsubishi M80 Control
Next Level Control
The Mitsubishi M80 controller boasts 3 channels for superimposition (for 3 tools in the cut). Additionally multiple cutting-edge features are included that enhance machining efficiency, accuracy, and ease of use. Starting with a high-speed processor, the M80 offers rapid data processing and seamless operation, ensuring that complex machining tasks are executed flawlessly. Its user-friendly interface, highlighted by a high-resolution touchscreen, simplifies the setup and monitoring processes, allowing operators to interact more intuitively with the system. The M80 also supports advanced programming capabilities, including 3D simulation and VCC (Vibration Cutting Control) which generates feed axis vibration during machining, breaking the chip into smaller ones. This advancement reduces the time required to evacuate chips and also increases the efficiency of the machine overall.
Included Hardware
Extraordinary, Innovative Features
- Chip Conveyor
- Parts Conveyor
- Long Work Piece
-
Ruben Salitillo
,
Engineering Manager, Appleton Mexico Group
Previously, all 12 parts were being made in 2-3 operations. We now manufacture them ALL in 1 operation on the Eurotech. Our quality greatly improved, and we realized a cycle time improvement of over 44%!
-
Pat Hundley
,
President, West Coast Manufacturing
The Eurotech machine allows us to machine the parts in one operation instead of two. This of course is a huge savings in time and improves part quality
-
Dan Anger
,
CNC Director, Schaeffer Screw Products
With the Eurotech SwissTurns we have a 33% cycle time savings and part inspection is down to 1-2 parts per hour. It’s really phenomenal!
-
Mark Lester
,
Production Manager, Coleman
The Eurotech SwissTurn solved our manufacturing problems. It took up minimal floor space, eliminated handling, improved accuracy and saved 37% in our cycle time. We now machine parts in one operation and with the free training are still increasing our productivity.
-
Gary North
,
President, Triax Precision Manufacturing
The Eurotech was able to cut our cycle times in half and reduced our operations down to one. We are now a ‘Done in One’ Shop!
